Texas Instruments LM1117MP-5.0/NOPB LDO Voltage Regulators
800-mA 15-V linear voltage regulator ; 4-SOT-223 0 to 125
Same model may have multiple batches, images only for reference.
Manufacturer
Part Number (MPN)
LM1117MP-5.0/NOPB
Detailed Description
Advanced Texas LM1117MP-5.0/NOPB LDO for precision electronics.
Package
SOT-223
Lifecycle Status
Active
RoHS State
RoHS Compliant
Datasheet
LM1117MP-5.0/NOPB Datasheet
Quick Jump:
Technical Specifications
Texas Instruments LM1117MP-5.0/NOPB LDO Voltage Regulators technical specifications.
General
RoHS
Compliant
Number of Pins
4
Number of Channels
1
Package / Case
TO-261-4, TO-261AA
Mounting Type
Surface Mount
Operating Temperature
0°C ~ 125°C
Supply Voltage
12 V
Lifecycle Status
Production
Manufacturer Lifecycle Status
ACTIVE
Package
SOT-223
Alternate Parts Comparison (LM1117MP-5.0/NOPB vs LM3S1332-EQC50-A2T vs LM3S1435-EQC50-A2 vs LM3S2533-EQC50-A2)
Side-by-side technical parameter comparison of related primary models in this product family.
| This Part | Alternate Parts | Alternate Parts | Alternate Parts | |
|---|---|---|---|---|
| Package / Case | TO-261-4, TO-261AA | 100-LQFP | 100-LQFP | 100-LQFP |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Operating Temperature | 0°C ~ 125°C | -40°C ~ 105°C (TA) | -40°C ~ 105°C (TA) | -40°C ~ 105°C (TA) |
| Supply Voltage | 12 V | 2.25V ~ 2.75V | 2.25V ~ 2.75V | 2.25V ~ 2.75V |
| Number of Pins | 4 | 100 | 100 | 100 |
| RoHS | Compliant | Yes | Yes | Yes |
| Package | SOT-223 | LQFP | LQFP | LQFP |
| Radiation Hardening | No | No | No | No |
| Schedule B | 8542390000 | 8542310000 | 8542310000 | 8542310000 |
| Data Bus Width | -- | 32bit | 32bit | 32bit |
| Core Processor | -- | ARM® Cortex®-M3 | ARM® Cortex®-M3 | ARM® Cortex®-M3 |
| Core Size | -- | 32-Bit Single-Core | 32-Bit Single-Core | 32-Bit Single-Core |
