STMicroelectronics STGB18N40LZT4 BJTs
Automotive-grade 390 V internally clamped IGBT ESCIS 180 mJ
Same model may have multiple batches, images only for reference.
Manufacturer
Part Number (MPN)
STGB18N40LZT4
Detailed Description
Automotive-grade 390 V internally clamped IGBT ESCIS 180 mJ
Package
TO-263-3, D2PAK (2 Leads + Tab), TO-263AB
Lifecycle Status
Active
Datasheet
STGB18N40LZT4 Datasheet
Quick Jump:
Technical Specifications
STMicroelectronics STGB18N40LZT4 BJTs technical specifications.
General
Series
PowerMESH™
Package / Case
TO-263-3, D2PAK
Mounting Type
Surface Mount
Operating Temperature
-55°C ~ 175°C (TJ)
Lifecycle Status
Active
Description
IGBT 420V 30A D2PAK
Detailed Description
IGBT 420 V 30 A 150 W Surface Mount D2PAK
Gate Charge
29 nC
Td on Off 25 C
650ns/13.5µs
Test Condition
300V, 10A, 5V
Alternate Parts Comparison (STGB18N40LZT4 vs STGB30H60DFB vs STGB15H60DF vs STGB10M65DF2)
Side-by-side technical parameter comparison of related primary models in this product family.
| This Part | Alternate Parts | Alternate Parts | Alternate Parts | |
|---|---|---|---|---|
| Package / Case | TO-263-3, D2PAK | TO-263-3, D2PAK | TO-263-3, D2PAK | TO-263-3, D2PAK |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Operating Temperature | -55°C ~ 175°C (TJ) | -55°C ~ 175°C (TJ) | -55°C ~ 175°C (TJ) | -55°C ~ 175°C (TJ) |
| Lifecycle Status | Active | Active | Active | Active |
| Current Collector IC Max | 30 A | 60 A | 30 A | 20 A |
| Current Collector Pulsed Icm | 40 A | 120 A | 60 A | 40 A |
| Description | IGBT 420V 30A D2PAK | IGBT TRENCH FS 600V 60A TO-263 | IGBT TRENCH FS 600V 30A TO-263 | IGBT TRENCH FS 650V 20A TO-263 |
| Detailed Description | IGBT 420 V 30 A 150 W Surface Mount D2PAK | IGBT Trench Field Stop 600 V 60 A 260 W Surface Mount TO-263 (D2PAK) | IGBT Trench Field Stop 600 V 30 A 115 W Surface Mount TO-263 (D2PAK) | IGBT Trench Field Stop 650 V 20 A 115 W Surface Mount TO-263 (D2PAK) |
| Gate Charge | 29 nC | 149 nC | 81 nC | 28 nC |
| Input Type | Logic | Standard | Standard | Standard |
| Power Max | 150 W | 260 W | 115 W | 115 W |
| Td on Off 25 C | 650ns/13.5µs | 37ns/146ns | 24.5ns/118ns | 19ns/91ns |
