Texas Instruments TMX320C6745PTP2 DSP (Digital Signal Processors)
IC DSP FLOATING POINT 176-HLQFP
Same model may have multiple batches, images only for reference.
Manufacturer
Part Number (MPN)
TMX320C6745PTP2
Category
Series
Detailed Description
IC DSP FLOATING POINT 176-HLQFP
Package
176-LQFP Exposed Pad
Key Features
Package / Case: 176-LQFP Exposed Pad; Mounting Type: Surface Mount
Lifecycle Status
Obsolete
RoHS State
RoHS Compliant
Datasheet
TMX320C6745PTP2 Datasheet
Quick Jump:
Technical Specifications
Texas Instruments TMX320C6745PTP2 DSP (Digital Signal Processors) technical specifications.
General
Interface
Ethernet MAC, I²C, McASP, SPI, UART, USB
Package / Case
176-LQFP Exposed Pad
Mounting Type
Surface Mount
Operating Temperature
0°C ~ 90°C (TJ)
Lifecycle Status
Obsolete
Type
Fixed/Floating Point
Clock Rate
200MHz
Non Volatile Memory
External
On Chip RAM
320kB
Voltage IO
1.8V, 3.3V
Related Parts Comparison (TMX320C6745PTP2 vs TMS320F28375SPZPQR vs TMS320F28035PNT vs TMS320F28027PTT)
Side-by-side specifications of related catalog parts.
Engineering verification required. Related parts may have different electrical ratings, pinouts, footprints, and operating limits. Verify suitability for your circuit before substitution.
| This Part | Related Part | Related Part | Related Part | |
|---|---|---|---|---|
| Package / Case | 176-LQFP Exposed Pad | 100-TQFP Exposed Pad | 80-LQFP | 48-LQFP |
| Operating Temperature | 0°C ~ 90°C (TJ) | -40°C ~ 125°C (TA) | -40°C ~ 105°C (TA) | -40°C ~ 105°C (TA) |
| Lifecycle Status | Obsolete | Active | Production | Production |
| Mounting Type | Surface Mount | -- | Surface Mount | Surface Mount |
| Interface | Ethernet MAC, I²C, McASP, SPI, UART, USB | -- | CAN, I2C, LIN, SCI, SPI, UART | I2C, SCI, SPI, UART, USART |
| Supply Voltage | -- | 1.14V ~ 3.47V | 1.71V ~ 1.995V | 3.3 V |
| Core Processor | -- | C28x | C28x | C28x |
| Core Size | -- | 32-Bit Single-Core | 32-Bit Single-Core | 32-Bit Single-Core |
| RAM Size | -- | 82K x 16 | 20 kB | 12 kB |
| Connectivity | -- | CANbus, I²C, McBSP, SCI, SPI, uPP, UART/USART, USB | CANbus, I²C, LINbus, SCI, SPI, UART/USART | I²C, SCI, SPI, UART/USART |
| Data Converters | -- | A/D 14x12b; D/A 3x12b | A/D 16x12b | A/D 13x12b |
| Number of I/O | -- | 41 | 45 | 22 |
