Texas Instruments MSPM0G1107TRHBR Microcontrollers
80MHz Arm® Cortex®-M0+ MCU with 128KB flash 32KB SRAM 2x12-bit 4Msps ADC, op-amp 32-VQFN -40 to 105
Same model may have multiple batches, images only for reference.
Manufacturer
Part Number (MPN)
MSPM0G1107TRHBR
Detailed Description
Advanced Texas MSPM0G1107TRHBR Microcontrollers for precision electronics.
Package
VQFN
Lifecycle Status
Active
RoHS State
RoHS Compliant
Datasheet
MSPM0G1107TRHBR Datasheet
Quick Jump:
Technical Specifications
Texas Instruments MSPM0G1107TRHBR Microcontrollers technical specifications.
General
RoHS
Compliant
Number of Pins
32
Lifecycle Status
Production
Manufacturer Lifecycle Status
Active
Package
VQFN
Number of UART Channels
4
Height
1 mm
Length
5 mm
Thickness
900 µm
Width
5 mm
Related Parts Comparison (MSPM0G1107TRHBR vs MSPM0L1105TRGER vs MSPM0L1306TDGS20R vs MSPM0L1305SRGER)
Side-by-side specifications of related catalog parts.
Engineering verification required. Related parts may have different electrical ratings, pinouts, footprints, and operating limits. Verify suitability for your circuit before substitution.
| This Part | Related Part | Related Part | Related Part | |
|---|---|---|---|---|
| RoHS | Compliant | Yes | Yes | Yes |
| Lifecycle Status | Production | Active | Active | Active |
| Package | VQFN | VQFN (RGE)-24 | 20-VSSOP | VQFN (RGE)-24 |
| Number of ADC Channels | 9, 11, 16, 17 | -- | 8 Channel | 10 Channel |
| Package / Case | -- | 24-VFQFN Exposed Pad | 20-TFSOP | 24-VFQFN Exposed Pad |
| Mounting Type | -- | Surface Mount | Surface Mount | Surface Mount |
| Operating Temperature | -- | -40°C ~ 105°C (TA) | -40°C ~ 105°C (TA) | -40°C ~ 125°C (TA) |
| Supply Voltage | -- | 1.62V ~ 3.6V | 1.62V ~ 3.6V | 1.62V ~ 3.6V |
| Core Processor | -- | ARM® Cortex®-M0+ | ARM® Cortex®-M0+ | ARM® Cortex®-M0+ |
| Core Size | -- | 32-Bit | 32-Bit | 32-Bit |
| RAM Size | -- | 4K x 8 | 4K x 8 | 4K x 8 |
| Connectivity | -- | DALI, I²C, IrDA, LINbus, SmartCard, SMBus, SPI, UART/USART | DALI, I²C, IrDA, LINbus, SmartCard, SMBus, SPI, UART/USART | DALI, I²C, IrDA, LINbus, SmartCard, SMBus, SPI, UART/USART |
| Action |
Cross Reference
Manufacturer-stated alternates from official cross-reference tools. These are not a guaranteed pin-compatible drop-in. Qualify package, pinout, and electrical limits against the datasheet before a board change. See cross-reference vs drop-in compatible .
Suggested replacements
MKE17Z256VLF7NXP SemiconductorsNXP
IC MCU 32BIT 256KB FLASH 48LQFP
More Parts in Microcontrollers
Browse additional parts from the same category, grouped by series, package type, and manufacturer. These are catalog suggestions — not verified pin-compatible alternates.
MSP430FR2433IRGERTexas Instruments16 MHz MCU with 16KB FRAM, 4KB SRAM, 10-bit ADC, UART/SPI/I2C, timer 24-VQFN -40 to 85
MSP430F2132TRHBRTexas Instruments16 MHz MCU with 8KB Flash, 512B SRAM, 10-bit ADC, comparator, I2C/SPI/UART 32-VQFN -40 to 105
