Texas Instruments TLC2274CNE4 Operational Amplifiers, Instrumentation Amplifiers and Buffer Amplifiers
Quad operational amplifier featuring rail-to-rail output and low noise.
Same model may have multiple batches, images only for reference.
Manufacturer
Part Number (MPN)
TLC2274CNE4
Category
Detailed Description
Quad operational amplifier featuring rail-to-rail output and low noise. This general-purpose amplifier offers a 2.2MHz bandwidth and a 3.6V/µs slew rate. It operates from a dual supply voltage range of 2.2V to 8V, with a maximum single supply of 16V. Key specifications include a 70dB CMRR, 60pA input bias current, and 300µV input offset voltage. The component is housed in a 14-PDIP package.
Package
N
Lifecycle Status
Active
RoHS State
RoHS Compliant
Datasheet
TLC2274CNE4 Datasheet
Quick Jump:
Technical Specifications
Texas Instruments TLC2274CNE4 Operational Amplifiers, Instrumentation Amplifiers and Buffer Amplifiers technical specifications.
General
Series
LinCMOS™
RoHS
Yes
Number of Channels
4
Packaging
Rail/Tube
Operating Temperature
-40°C ~ 125°C
Supply Voltage
8V
Amplifier Type
GENERAL PURPOSE
Bandwidth
2.2MHz
Package
N
CMRR
70dB
Alternate Parts Comparison (TLC2274CNE4 vs TLC5926IDBQR vs TLC7226CN vs TLC393CPSR)
Side-by-side technical parameter comparison of related primary models in this product family.
| This Part | Alternate Parts | Alternate Parts | Alternate Parts | |
|---|---|---|---|---|
| Operating Temperature | -40°C ~ 125°C | -40°C ~ 85°C (TA) | 0°C ~ 70°C | 0°C ~ 70°C |
| Supply Voltage | 8V | 3V ~ 5.5V | 15V | 5V |
| RoHS | Yes | Yes | Yes | Yes |
| Lead Free | Lead Free | Lead Free | Lead Free | Lead Free |
| Package | N | SSOP | N | SOP |
| Package Quantity | 25 | 2500 | 20 | 2000 |
| Radiation Hardening | No | No | No | No |
| Series | LinCMOS™ | -- | TLC7226 | LinCMOS™ |
| Number of Channels | 4 | -- | 4 | 2 |
| Height | 4.57mm | 1.5mm | 4.57mm | -- |
| Length | 19.3mm | 8.75mm | 24.33mm | -- |
| Output Current | 50mA | 120mA | -- | 20mA |
| Action |
Texas Instruments TLC2274CNE4 Operational Amplifiers, Instrumentation Amplifiers and Buffer Amplifiers Overview
Quad operational amplifier featuring rail-to-rail output and low noise. This general-purpose amplifier offers a 2.2MHz bandwidth and a 3.6V/µs slew rate. It operates from a dual supply voltage range of 2.2V to 8V, with a maximum single supply of 16V. Key specifications include a 70dB CMRR, 60pA input bias current, and 300µV input offset voltage.
The component is housed in a 14-PDIP package.
