Analog Devices AD8542ARMZ-REEL Amplifiers - Op Amps, Buffer, Instrumentation
Operational Amplifier, 2 Func, 7000uV Offset-Max, CMOS, PDSO8
Same model may have multiple batches, images only for reference.
Technical Specifications
Analog Devices AD8542ARMZ-REEL Amplifiers - Op Amps, Buffer, Instrumentation technical specifications.
General
Alternate Parts Comparison (AD8542ARMZ-REEL vs AD5621BKSZ-REEL7 vs AD8065ARZ-REEL7 vs AD8628ARZ-REEL7)
Side-by-side technical parameter comparison of related primary models in this product family.
| This Part | Alternate Parts | Alternate Parts | Alternate Parts | |
|---|---|---|---|---|
| Package / Case | 8-TSSOP | 6-TSSOP | 8-SOIC | 8-SOIC |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Operating Temperature | -40°C ~ 125°C | -40°C ~ 125°C | -40°C ~ 85°C | -40°C ~ 125°C |
| Supply Voltage | 2.7 V ~ 5.5 V | 2.7 V ~ 5.5 V | 5 V ~ 24 V | 3 V |
| Number of Pins | 8 | 6 | 8 | 8 |
| Number of Channels | 2 | 1 | 1 | 1 |
| RoHS | Compliant | Compliant | Compliant | Compliant |
| Lifecycle Status | Production | Production | Production | Production |
| Contact Plating | Tin | Gold | Tin | Tin |
| Manufacturer Lifecycle Status | PRODUCTION | PRODUCTION | PRODUCTION | PRODUCTION |
| Output Type | Rail-to-Rail | Voltage | Rail-to-Rail | Rail-to-Rail |
| Package | MSOP | SC | R | R |
| Action |
Analog Devices AD8542ARMZ-REEL Amplifiers - Op Amps, Buffer, Instrumentation Overview
AD8542ARMZ-REEL is a dual CMOS operational amplifier from Analog Devices, designed for low-power, single-supply analog applications. It features rail-to-rail input and output operation, a 1 MHz gain bandwidth product, and low supply current, making it suitable for battery-powered systems, sensor interfaces, signal buffering, and general-purpose analog signal conditioning. The device is supplied in an 8-MSOP surface-mount package with tape-and-reel packaging for automated assembly.
Key Features
Dual operational amplifier, 2 channels
CMOS rail-to-rail input and output architecture
Single-supply operation from 2.7 V to 5.5 V
Low supply current: 45 μA per amplifier
Gain bandwidth product: 1 MHz
Low input bias current, suitable for high-impedance signal sources
Unity-gain stable
No phase reversal
Output current up to 30 mA per channel
Extended operating temperature range: -40°C to +125°C
8-MSOP surface-mount package
Tape and reel packaging for production use
Target Applications
Sensor interface circuits
Battery-powered and portable electronics
ASIC input/output buffering
Signal conditioning circuits
Active filters and gain stages
Photodiode and piezoelectric sensor amplifiers
Medical instrumentation
Mobile communication devices
Audio output circuits
General-purpose low-power analog amplification
AD8542ARMZ-REEL is a dual CMOS operational amplifier from Analog Devices, designed for low-power, single-supply analog applications. It features rail-to-rail input and output operation, a 1 MHz gain bandwidth product, and low supply current, making it suitable for battery-powered systems, sensor interfaces, signal buffering, and general-purpose analog signal conditioning.
More Parts in Operational Amplifiers, Instrumentation Amplifiers and Buffer Amplifiers
ADA4528-2ARMZ-R7Analog Devices
